Product Specifications
Inputs:
Two balanced XLR inputs. One Monitor input jack
Output:
One stereo 3.5mm (1/8”) Mini-Jack output
Control Knobs:
Left and Right Control Knobs adjust the signal of each channel to the optimum recording levels. Volume control knob adjusts the headphone volume level.
Mono/Stereo Switch:
select mono or stereo output mode. The mono mode is for one mono microphone recording. It can send the mono audio signal to each channel and output stereo audio signal. The stereo mode is for two channels recording. It provides two separate channels of au
LINE/ MC/ PH Switches:
Select LINE or MIC or Phantom levels
Level Meter:
-18 to +3 dB in 3 dB increments
LED/ Peak Indicators:
Switch on/off the LED signal indicators which flash red for overload
Gain Switch:
Selects LO for unity gain or HI for +20dB boost
MONITOR:
Headphone jack to monitor the audio from microphones or camera
AGC:
On/ Off Switch
AGC DSBL:
Camera Auto Gain Control will increase the gain to maximum level; the AGC Disable function reduces the hiss when the camera is recording during quiet moments.
Input Level:
3 dBu / +14dBu
Output Level:
Nominal MIC levels
THD:
Less than 0.01% @ 1 kHz, -30dBu input
S/N Ratio:
85 dB @ 1 kHZ, - 30dBu input
Gain:
0 dB / 20 dB
Phantom Power:
Dual regulated 12 or 48 V power supplies. Current to 14 mA (direct short)
Dimensions:
152 x 95 x 44mm
Weight:
0.51kg
Box Contents:
SR-AX107 main unit, signal transmission line x 1, AV cable x 1, user manual, warranty card
